Our Dutch Weave Wire Cloth Offer Strength and Rigidity Along With Fine Filtration Capabilities.

Dutch Woven Wire Cloth is made with a combination of big weft wires and small warp wires, this enables a strong wire cloth with super fine filtration.

Dutch weave stainless steel wire cloth is commonly used as industry filter media, offer strength and rigidity along with fine filtration capabilities.

Our Dutch weaving filter cloth is available in various meshes and weaves, including plain Dutch weave, twilled Dutch weave, and reverse Dutch weave. They are available in either 300 series stainless steels, specialized stainless steels and Nickel based Alloys.

There are three pieces of plain dutch and twilled dutch weave wire cloth sample

Plain Dutch Weave Wire Cloth

Plain Dutch weave cloth same as plain weaving square mesh, the difference is the diameter of the warp wire is larger than the weft wire.

The plain Dutch weave cloth is formed by weaving a limited number of warps wires with the maximum number of weft wires woven tightly together, producing a cloth with no readily visible aperture. the shape and position of the openings aid particle retention and increase filter cake formation.

Plain Dutch weave mesh is strong and stable, easy to clean and with a good flow rate suitable for high-pressure liquid/solid separation.

This is a drawing for plain Dutch weave wire cloth pattern

This is a macro photo for 30x150mesh plain dutch weave wire cloth

30×150mesh Plain Dutch Weave Wire Cloth

This is a macro photo for 24x120 mesh plain dutch weave wire cloth

24×120mesh Plain Dutch Weave Wire Cloth

30×150mesh Plain Dutch Weave Wire Cloth

This is a macro photo for 40x200 mesh plain dutch weave wire cloth

40×200mesh Plain Dutch Weave Wire Cloth

Plain Dutch Weave Wire Cloth, Stainless Steels In Stock
Mesh No.	Wire dia.(mm)	Wire dia.(inch)	Fineness of	Weight	Weight
(warp/inch & weft/inch)	(warp & weft)	(warp & weft)	Filtering(micron)	(lb/square yard)	(kg/square meter)
8/85	0.355/0.320	0.0140/0.01260	318-340	0.497	2.43
10/70	0.600/0.350	0.0240/0.01400	300-325	0.622	3.04
12/64	0.580/0.400	0.0230/0.01650	295-305	0.744	3.64
14/88	0.500/0.330	0.0190/0.01200	195-205	0.644	3.15
20/150	0.248/0.177	0.0098/0.00700	155-165	0.303	1.48
24/110	0.355/0.250	0.0150/0.01000	145-155	0.552	2.70
24/120	0.330/0.230	0.0130/0.00900	115-125	0.458	2.24
30/150	0.230/0.180	0.0090/0.00700	95-105	0.327	1.60
40/200	0.180/0.140	0.0070/0.00550	75-85	0.266	1.30
50/250	0.140/0.114	0.0055/0.00450	55-65	0.204	1.00
60/300	0.140/0.090	0.0055/0.00350	36-40	0.157	0.77
70/400	0.120/0.065	0.0047/0.00256	36-40	0.138	0.67
80/300	0.125/0.090	0.0049/0.00350	38-42	0.200	0.98
80/400	0.125/0.071	0.0049/0.00280	38-42	0.166	0.81

Plain Dutch Weave Wire Cloth

Dutch weave is similar to plain Dutch weave, except that the wires cross two under and two over, allowing heavier wires and higher mesh counts.

In a twill Dutch weaving wire mesh, the weft wires are drawn up so tightly that there is always a weft wire above and below the warp wires, creating a weave with the warp wires completely covered.

Twilled Dutch weaves offer even greater strength and finer filtration ratings. In a twilled weave, the flow-pass geometry is extremely tortuous, allowing reasonable flow rates while insuring excellent particle size retention.

This is a drawing for twill dutch weave wire cloth pattern

50×500mesh Twill Dutch Weave Wire Cloth

20×200mesh Twill Dutch Weave Wire Cloth

Twill Dutch Weave Wire Cloth, Stainless Steels In Stock
Mesh No.	(warp/Wire dia.(inch)	Wire dia.(mm)	Fineness of	Weight	Weight
inch & weft/inch)	(warp & weft)	(warp & weft)	Filtering(micron)	(lb/square yard)	(kg/square meter)
20×200	0.0135x0.0105	0.30×0.27	138	0.804	3.93
24×220	0.0135x0.0100	0.30×0.25	105-112	0.814	3.98
20×250	0.0098x0.0079	0.25x0.20	98-105	0.575	2.81
30×360	0.0100x0.0060	0.25×0.15	80-84	0.509	2.49
40×560	0.0070x0.0040	0.18×0.10	47-52	0.352	1.72
50×500	0.0055x0.0043	0.14×0.11	37-45	0.36	1.76
80×700	0.0040x0.0030	0.10×0.08	24-26	0.27	1.32
120×160	0.0040x0.0025	0.10×0.063	28-32	0.094	0.46
120×400	0.0040x0.0025	0.10×0.063	37-43	0.143	0.7
165×800	0.0028x0.0020	0.071×0.05	14-16	0.148	0.72
165×1400	0.0028x0.0016	0.071×0.04	9-11	0.157	0.77
200×600	0.0024x0.0018	0.061x0.046	19-21	0.103	0.5
200×1400	0.0028x0.0016	0.071x0.04	5-6	0.17	0.83
250×2000	0.0015x0.0011	0.040×0.028	4-5	0.1	0.49
325×2300	0.0014x0.0010	0.035×0.025	2-3	0.094	0.46
400×2800	0.0011x0.0009	0.028×0.022	1-2	0.083	0.41
400×3200	0.0010x0.0007	0.030×0.019	1	0.075	0.37
500×3500	0.0009x0.0006	0.025×0.017	1	0.067	0.33

Features

We offer a wide range of metals and alloys to provide the best material or combination of materials for the Dutch weaving wire cloth filter mesh. Common used types in stock and Special specifications can be customized upon customers' requirements.

Dutch Weave Metal wire mesh have the many advantages than square opening wire mesh, it is a best micronic filter media.

Allowing reasonable flow rates while insuring excellent particle size retention.
Flexible with excellent filtration performance
High hardness, good load strength, suitable for high-pressure liquid/solid separation.
High temperature resistance
Corrosion and rust resistance.
Zero aperture, Light-proof woven.
High resistance due to tight wire position.
Extreme low absolute grade of fineness (down to 2– 3 μm).
Acid and alkali resistance.

Applications

Widely used as Extruder screens also named extruder screen mesh, that o be used at plastic or rubber processing machine to keep mixing of foreign particles away from
Finest filtration in hydraulic systems, especially for critical applications, such as aero-space and fuel. E extrusion product.
High tensile Warp wire for Auto-Screen changers used in the Plastic Extrusion Industry.
Best micronic filter media for pharmacy, food, medicine, chemical and other industries.
